(Aluminum Tank)
- CE approval.
- Three operation modes as,
- a. Lubrication: The lubricator runs via lubrication time after power-on.
- b. Intermittence: The lubricator runs via intermittent time after power-on.
- c. Memory: The lubricator runs via the previous set after power-on.
- Lubrication and intermittent time can be adjusted.
- The float switch alarms and output signal when the oil level is low.
- The pressure release device is included.
- The over temperature/load protector is attached to protect the motor.
- The function of fixed pressure for the pressure relief valve can prolong the system life
- Lubrication time (second/minute) and intermittent time (second/minute/hour/cycle) are adjustable.
- The indicator on the panel can display the operation of the lubricator.
- The intermittent period can be adjusted via the machine’s action cycles.
- Pressure switch is an option for YET-A2P2.
- “RES” key can force the lubricator to function.
Model | YET-A2 | YET-A2P2 | ||
Voltage (Single Phase) | 110V or 220V | 110V or 220V | ||
Consumption Power (W) | 100 | 100 | ||
Capacity of Terminal Output (A) | 3 | 3 | ||
Lubrication time (second/minute) | 1-999 | 1-999 | ||
Intermittent Time (second/minute/hour/cycle) | 1-999 | 1-999 | ||
Output Bore | Ø4 or Ø6 | Ø4 or Ø6 | ||
Max. Output Pressure Mpa (kgf/cm2) | 1.5 (15) | 1.5 (15) | ||
Output Volume (cc/mm) | 150 | 150 | ||
Pressure Release device | O | O | ||
Float Switch | O | O | ||
Pressure Switch (kgf/cm2) | X | 12-9 | ||
Pressure Gauge | O | O | ||
Alarm Beeper | O | O | ||
Tank Capacity (L) | 2 | 3 | 4 (Transparent Plastic Tank) |
4 (Aluminum Tank) |
Weight (kg) | 2.7 | 2.9 | 3.3 | 3.7 |
Note: Because of continuous improvements, above specifications are subject to change without prior notice. |
