- The float switch alarms and output signal when the oil level is low.
- The function of fixed pressure for the pressure relief valve can prolong the system life
- The motor is of long-time operation.
- The pressure release device is included.
- The power indicator displays the operation of the lubricator.
- “Feed” key can force the lubrication to function. (cooperate with PLC control system).
Model | YAJ | |||
Voltage (Single Phase) | 110V or 220V | |||
Consumption Power (W) | 56 | |||
Output Power (W) | 25 | |||
Capacity of Terminal Output (A) | 0.3 (Float Switch) 3 (Pressure Switch) |
|||
Lubrication time (second/minute) | Cooperate with PLC control system | |||
Intermittent Time (second/minute/hour/cycle) | Cooperate with PLC control system | |||
Output Bore | Ø4 or Ø6 | |||
Max. Output Pressure Mpa (kgf/cm2) | 2 (20) | |||
Output Volume (cc/ min) | 150 | |||
Pressure Release device | O | |||
Float Switch | O | |||
Pressure Switch (kgf/cm2) | X (Option) | |||
Pressure Gauge | O | |||
Alarm Beeper | X | |||
Tank Capacity (L) | 3 | 4 | 8 | 20 |
Weight (kg) | 4.4 | 4.8 | 8.5 | 17.1 |
Note: Because of continuous improvements, above specifications are subject to change without prior notice. |
